Media: 2x CFast 2.0 card slots, 2x SD UHS-II card slots, 1x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and ProRes recording.
SDI Compliance: SMPTE 292M, SMPTE 424 level A and B, SMPTE 2081-1, SMPTE 2082-1.
Computer Interface: USB Type-C 3.1 Gen 1 for external drive recording and software updates.
Remote Control: 2x 2.5mm LANC input for Rec Start/Stop, plus Iris and Focus control using compatible lenses.
Reference Inputs: Tri-Sync/Black Burst/Timecode.
Analog Audio Outputs: 1x 3.5mm headphone jack, supports iPhone microphone for talkback.
Analog Audio Inputs: 2x XLR analog switchable between mic, line and AES audio.
Total Video Outputs: 1x SDI, 1x SDI Monitoring.
Timecode Clock: Highly accurate timecode clock.
Controls: Touchscreen menus on 4 inch screen.
Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Metadata Support: Automatically populated lens data from electronic EF, B4 and i/Technology compatible PL lenses.
Screen Type: LCD capacitive touchscreen.
Scene average auto exposure in video mode.
Iris Control: Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode.
Focus: Focus button turns on peaking, auto focus available using compatible lenses.
Built in ND Filters: Four position ND filter wheel with clear, 2-stop, 4-stop and 6-stop ND filters.
High Speed Frame Rates: Blackmagic RAW 8:1 4.6K Full - Up to 120 fps UHD Windowed - Up to 150 fps HD Windowed - Up to 300 fps, ProRes 422 HQ 4.6K Full - Up to 80 fps UHD Windowed - Up to 120 fps HD Windowed - Up to 240 fps.
Frame Rates: Maximum sensor frame rate dependent on resolution and codec selected.
Lens Control: Electronic control via EF mount pins or 12pin broadcast connector for compatible lenses.
Interchangeable with optional PL, B4 and F lens mounts.
Effective Sensor Size: 25.34mm x 14.25mm (Super35).
